1. With SMD 3535 LED lamp, which is much better than DIP for rental screen:
2. Super slim and super light, fast installation,The cabinet size is 500*500*86mm,saving a lot of
space.
The weight is only 7.5KG/cabinet.This saves much transportation
cost and labor cost.
3. IP65 protection level, waterproof. Strong weather resistance, can be used in various
severe
environments.
4. Adjustable Brightness to fit both indoor and outdoor rental use.
5. High refresh rate from 2000Hz to 4800Hz, offers the best effect of live broadcast.
6. Hanging design. Traditional cabinet is too heavy to hang--one cabinet is usually
40-50KG,
needs 3 or 4 persons to move it. But our model can easily be hung.
| Pixel Pitch | 10.4mm |
| Pixel Configuration | SMD 3in1 |
| LED Encapsulation | SMD3535 |
| Resolution | 9210 dots/m² |
| Birghtness | 5000 cd/m² |
| Color Temperature | 3200K--9500K |
| Drive Mode | 1/3 |
| Cabinet Size | 500mm×500mm×100mm |
| Cabinet Resolution | 48 dots×48 dots |
| Cabinet Weight | 7 kg |
| Max Power Consumption | 900W/m² |
| Average Power Consumption | 450W/m² |
| Best Viewing Angle | Horizontal≤120°Vertical≤120° |
| Refresh Rate | 360--4800 (adjustable) |
| Grey Scale | 12--16bit (adjustable) |
| Protection Level | IP65 |
| Cabinet Material | Die-casting Aluminum |
| Best Viewing Distance | 15m--50m |
| Mean Time between Failures | > 10000 hours |
| To Floor Drain Current | < 3.5 mA |
| Dielectric Strength | AC 1500V |
| Operating Voltage | 220V/50Hz 110V/60Hz |
| System Working Environment Humidity | 10%--90% |
| System Working Environment Temperature | -20--+50°C |
Advantages:
1. casting aluminum, no rust
2. light weight , only 9.8KG/cabinet, easy to move
3. fast installation design, easy to install or disassemble
4. IP 65 waterproof
5. no noise design, which is suitable for all kind of show
6. strong press , car can pass on it
7. no frame support, put the cabinet directly on the flat floor
8. energy saving
