Product Features:
1. SMD led encapsulation confirm wide view distance and good
uniformity
2. High brightness,good waterproof
IP65,anti-corrosion,anti-rust,long life span>100000hours
3.High pixel density, high resolution and high definition,perfect
display vision
4. Lower power consumption,good heat dissipation,low noise created.
5. Cabinet with locks,connectors,easy and quick to assemble without tools in short time
6. Widely used for commercial display,advertising, stage
background,mobile display. traffic display,sports led display etc.
Specifications :
| Pixel pitch | 6mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD3535 |
| Size of module | 192mm x 192mm |
| Resolution of module | 32 x32dots |
| Size of cabinet | 768mm X 768mm x 150mm/960mm x 960mm x 150mm |
| Resolution of cabinet | 128x 128 dots/160x160dots |
| Material of Cabinet | Iron/Aluminum |
| Weight of Cabinet | 30/45KGS |
| Brightness | >6800cd/sq.m |
| Density | 27777dots/sq.m |
| Best viewing angle | 140 /140 |
| Pixel Configuration | 1R1G1B |
| Best viewing distance | 5-60M |
| Maximum power consumption | 1000W/sq.m |
| Average power consumption | 560W/sq.m |
| Driving method | 1/4 scan |
FAQ:
What is the life time for a LED screen?
The life time for the LED screen is basically over 100,000 hours,
but it depends how the client is taking care of his LED screen and
how it is used. When a LED Screens´ life time gets to 100,000
hours, it means that the brightness of the LED lamps of the LED
screen is about 50% off as compared to the original brightness
depending on several factors that will enlarge a LED screen´s life
time or reach 100,000 hours.
What is the led chip packing?
546 oval lamp/346 oval lamp/SMD 3528/8X8 Array module
How to protect power supply?
Electrical peaks can put more force on the electrical components
which will decrease life time .
it is wise to install a protection (voltage stabilizer) that can
control the peaks.
How to main the led screen?
The soldering of the LED chips can dry out and break which require
changing often components such as LED modules and receiving card .
What is the return policy?
If the module died exceed 1%,we can resend you the new one.
