Waterproof P7.62 Flexible Led Curtain Display Stage Backgrond Led
Screen
1. Quick Detail:
1, Accurate color uniformity and smoother, flicker-free video
2. Low noise generation and high cost-performance ratio
3. Cabinet connection angle can be adjusted by -15 degree to +15
degree
4. Light weight and super transparency ratio
6. Fast Lock System & No Fan Design
2. Description:
Dosatronics LED displays are high tech product with our own patent.
Especially outdoor LED display for advertising has high brightness,
high contrast, high refresh rate…All are popular both in domestic
and overseas market. We adopt unbeatable product stability through
strict Quality Control System. It is very correct for you to choose
our company, our LED display products. All of them has 3 years
quality warranty since all component are extremely good. They can
bring you large fortune in a very short time.
3. Applications:
Our Full Color SMD Outdoor P6 LED Display is mainly for outdoor
usage, such as commercial advertising,
mobile media, night club, entertainment events, business
establishments, can install in banks, stock exchange
centers, bus station, schools, telecommunications, customs,
stadiums, studio, shopping, malls, railways,
airports, harbors, etc.
4. Specifications:
| Model No. | IRC |
| Pixel Pitch | 7.62mm |
| Module Size | 305mm*366mm |
| Module Resolution (W*H) | 40 dots*48 dots |
| Pixel Density | 17222 dots/ ㎡ |
| LED Type | SMD 3528 |
| Pixel Configuration | 1R1G1B |
| Wavelength (R.G.B) | R:625±2nm G:525±2nm B:470±2nm |
| Drive Mode | Dynamic 1/8 Duty Constant Current |
| Cabinet Size | 610×732×75mm |
| Cabinet Resolution | 80dots×96dots |
| Brightness | ≥1500cd/㎡ |
| Contrast | ≥2000:1 |
| Viewing Angle | 140°(Horizontal )/140°(Vertical ) |
| Best Viewing Distance | 7m-300m |
| Grey Scale | 10bits/1024levels |
| Color Capability | 16777216 |
| Color Temperature | 5000-9300K |
| Maximum Power Consumption | 500 W/m2 |
| Average Power Consumption | 200 W/m2 |
| Working Voltage | AC 220V/110V s±15% 50-60 HZ |
| Frame Frequency | 60-85 HZ |
| Refresh Frequency | 240 - 1000HZ |
| Brightness Correction | Pixel, Module, Cabinet Correction |
| Operating Temperature | -40~+65℃ |
| Operating Humidity | 10-90% RH |
| LED Lifespan | 100,000 hours |
Application:
Stadium perimeter,weddings, openings, promotions customs, stadiums,
studio, railways, airports, harbors, shopping malls, such as
banks,schools, telecommunications, night club, business
establishments, entertainment events,mobile media, bus
station,Commercial advertising, stock exchange centers,etc;
