    320x320mm Outdoor Advertising LED Display Screen

    Front Assemble Outdoor Advertising LED Display Screen For Cultural Promotion / 320mm X 320mm


    Nowadays,the led display for advertisement widely use in the world.Especially the back access outdoor led billboard.But sometimes there is no maintenance space behind the led display,we can consider front maintenance,our fast lock front service led module is meet this applicaion.
    See features as below:


    1, Maintenance can be from front or rear side.The led billboard module designed to 2 locks use T-tool, it is more easier and faster than the 8 screw holes of traditional led module.
    2, It can be installed without taking the space for back maintenance channel into consideration, thus improving your work efficiency.
    3, Long-term Brightness:more than 7000nit brightness throughout product lifetime of the LED display
    4, It Controlled with PC by synchronization, with high refresh rate.Sure Async control is also avaliable.


    Product Features:

    1. SMD led encapsulation confirm wide view distance and good uniformity

    2. High brightness,good waterproof IP65,anti-corrosion,anti-rust,long life span>100000hours

    3.High pixel density, high resolution and high definition,perfect display vision

    4. Lower power consumption,good heat dissipation,low noise created.

    5. Cabinet with locks,connectors,easy and quick to assemble without tools in short time

    6. Widely used for commercial display,advertising, stage background,mobile display. traffic display,sports led display etc.


    LED MODULE
    Module designFast front access with T-tool
    Pixel pitch8MM10MM16MM
    Led lampSMD3535DIP346 / SMD3535DIP346 / SMD3535
    Pixel configuration15625dot/m210000dot/m23906dot/m2
    Module dimension320mm x 320mm
    Module resolution40 dots x 40 dots32dots x 32dots20dots x 20dots
    Driving mode1/5 scan1/4 scanStatic state
    LED CABINET
    Cabinet size960mm x 960mm
    Cabinet materialIron or Aluminum as request
    Module quantity9pcs
    Cabinet weightAround 50kg/m2
    Power Max820w/m2650/800 (w/m2)500/750/(w/m2)
    Power average390w/m2325/400 (w/m2)250/375(w/m2)
    LED BILLBOARD
    Brightness>6000cd/m2>7500/5500(cd/m2)>7000/5000(cd/m2)
    Viewing angle

    H:120deg

    V: 120 deg.

    H:110deg /120deg

    V: 50deg/120deg

    H:110deg /120deg

    V: 50deg/120deg

    Power inputAC 110v /220V
    Brightness control256 levels
    Blind spot rate<1/10000
    Lifetime at 50% brightness100,000 hours
    Ingress ProtectionIP65
    Operation temperature﹣30 ℃ ~﹢50 ℃
    Storage temperature﹣60 ℃ ~﹢80 ℃
    Control wayStandard:Wired Optional:3G/4G/WIFI

    Input interface

    (with video processor)

    AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI, HDSDI

    Parameter
