320x320mm P16 LED Display Screen For Advertising Outdoor

Ask Lasest Price
Brand Name :	JuCaiYuan
Model Number :	Outdoor P16
Certification :	UL/CE/ROHS/FCC
Price :	negotiation
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	60000Sqm per month
Delivery Time :	5-10 days

Add to Cart

Product Details
Company Profile

320x320mm P16 LED Display Screen For Advertising Outdoor

Front Service Outdoor Led Billboard Advertising Screen Display 320 * 320 Mm P16 SMD

Nowadays,the led display for advertisement widely use in the world.Especially the back access outdoor led billboard.But sometimes there is no maintenance space behind the led display,we can consider front maintenance,our fast lock front service led module is meet this applicaion.
See features as below:

1, Maintenance can be from front or rear side.The led billboard module designed to 2 locks use T-tool, it is more easier and faster than the 8 screw holes of traditional led module.
2, It can be installed without taking the space for back maintenance channel into consideration, thus improving your work efficiency.
3, Long-term Brightness:more than 7000nit brightness throughout product lifetime of the LED display
4, It Controlled with PC by synchronization, with high refresh rate.Sure Async control is also avaliable.

Product Features:

1. SMD led encapsulation confirm wide view distance and good uniformity

2. High brightness,good waterproof IP65,anti-corrosion,anti-rust,long life span>100000hours

3.High pixel density, high resolution and high definition,perfect display vision

4. Lower power consumption,good heat dissipation,low noise created.

5. Cabinet with locks,connectors,easy and quick to assemble without tools in short time

6. Widely used for commercial display,advertising, stage background,mobile display. traffic display,sports led display etc.

Parameter

LED MODULE
LED Module design	Front Service with T-tool
Pixel pitch(mm)	16mm
Led lamp	SMD3535
Pixel configuration(dot/m2)	3906dot/m2
LED Module dimension(mm)	320mm x 320mm
LED Module resolution(dot)	20 dots x 20 dots
Driving mode	Static state
LED CABINET
Cabinet size(mm)	1280mm x 960mm / 960mm x 960mm
Cabinet material	Iron Cabinet or Aluminum Cabinet
Module quantity(pcs)	9pcs led modules
Cabinet weight(kg/m2)	50
Power Max(w/m2)	750w/m2
Power average(w/m2)	375w/m2
LED BILLBOARD
Brightness(cd/m2)	>5000cd/m2
Viewing angle(H/V)	Horizontal 110 deg. Vertical 50 deg.
Power input(V)	AC 110v /220V
Brightness control(level)	256 levels
Blind spot rate	＜1/10000
Lifetime at 50% brightness(h)	100,000 hours
Ingress Protection	IP65/IP54
Operation temperature	﹣30 ℃ ～﹢50 ℃
Storage temperature	﹣60 ℃ ～﹢80 ℃
Control way	Standard:Wired Optional:3G/4G/WIFI
Input interface(with video processor)	AV, S-Video, VGA, DVI, YPbPr, HDMI, SDI, HDSDI
