Outdoor P6 High Brightness SMD Full color Stadium LED Display For
Sports events
Product Features:
1. SMD led encapsulation confirm wide view distance and good
uniformity
2. High brightness,good waterproof
IP65,anti-corrosion,anti-rust,long life span>100000hours
3.High pixel density, high resolution and high definition,perfect
display vision
4. Lower power consumption,good heat dissipation,low noise created.
5. Cabinet with locks,connectors,easy and quick to assemble without tools in short time
6. Widely used for commercial display,advertising, stage
background,mobile display. traffic display,sports led display etc.
Technical Paremeter:
| Pixel pitch | 6mm |
| Pixel Configuration | 1R1G1B |
| LED component | SMD3535 |
| Size of module | 192mm x 192mm |
| Resolution of module | 32 x32dots |
| Size of cabinet | 768mm X 768mm x 150mm/960mm x 960mm x 150mm |
| Resolution of cabinet | 128x 128 dots/160x160dots |
| Material of Cabinet | Iron/Aluminum |
| Weight of Cabinet | 30/45KGS |
| Brightness | >6000cd/sq.m |
| Density | 27777dots/sq.m |
| Best viewing angle | 140 /140 |
| Pixel Configuration | 1R1G1B |
| Best viewing distance | 5-60M |
| Maximum power consumption | 1000W/sq.m |
| Average power consumption | 560W/sq.m |
| Driving method | 1/8 scan |
| Control method | Synchronization |
| Gray scale | 65536 |
| Colors | 256*256*256 |
| Color temperature | 3200-9300k |
| Uniformity | 97% |
| Working voltage | AC220V/110V±10% |
| Working temperature | -20ºC~+50ºC±10% |
| Working humidity | 10% ~ 90% |
| MTBF | 10,000 hours |
| Frame frequence | 50/60Hz |
| Refresh frequence | >1920Hz |
Installation :
1. We can assist the training and technical support for the
customer in the factory, if the customer requires so.
2. We could send our engineer to guide the installation for you.
But the relevant cost should be paid by your esteemed company.
3. Our technicians will offer CAD Drawing to show how to install
the LED Display rightly and fast, of course, if you need.
Our Service:
Pre-sales service :
Our team design and make solutions based on different requirements
from different customers, what you think is what we can do.
After-sales services:
1. We provide customer service through Skype, phone or email,
supply you video or drawing to solve problems.
2. We provide remote control service through internet to achieve
real time service, which will short time of solving problems.
3. We provide professional engineer one-to-one to keep fastly
reply.
Installation Service:
1. We provide detailed CAD drawing to customer for preparing metal
structure.
2. We could dispatch our engineer to your place , guide
installation and free training.
3. Special designs have special solutions; we will make perfect
solutions to satisfy all customers' requirements.
