P4 outdoor advertising led display outdoor led board p4 fixed led screen
1.LED cabinet can be customized as your LED display size;
2. The cabinet can be simple cabinet or with the backdoor as your request;
3.SMD 3 in 1 LEDs with wide viewing angle and great color uniformity;
4. Using high-quality LED chips, with high stability and reliability;
5.Adopt advanced production and processing technology to ensure the display quality and service life (100,000 hours);
6.Excellent service including free technical support,when in the warranty or out of the warranty;
7. Based on CE, FCC,ROHS Certification.
Specification
P4 SP4 outdoor advertising led display outdoor led board p4 fixed led screen
| Pixel Pitch | 4mm(H*V) |
| Pixel Density | 62500dots/m2 |
| LED Shape | SMD1921/2525 |
| LED Configuration | 1R1G1B |
| Module Size | 256*128mm |
| Module Resolution | 64 (W)×32 (H)pixels |
| Driving Mode | 1/8Scan,constant current |
| Cabinet Size | 512x512mm/768x768mm/1024x1024mm are avaliable |
| Brightness After Calibration | ≥5500cd/m2 |
| Contrast | 2000:1 |
| View Angle | 140°(horz.), 140°(vert.) |
| Best viewing distance | 4m-40m |
| Gray Scale | 12-16bits for red,green,blue |
| Colors | 16777216 |
| Input voltage (AC) | 110V ~ 240V |
| Frame Frequency | 50Hz-75Hz |
| Refresh Rate | ≥1920Hz |
| Stock Temperature | (-40℃~+85℃) |
| Operating Temperature | (-30℃~+50℃) |
| Operating Humidity | 10-90% RH |
| Life Span | 100,000Hours |
| MTBF | ≥50,000Hours |
| IP Rating(Front/Rear) | IP65/IP54 |
| Flatness of the screen | ≤1mm |
| Control Distance | CAT5E:100m,Multi-Mode Fiber:500m,Single-Mode Fiber:15km |
Project Cases
1,Indoor rental led display application cases
2,Outdoor rental led display application cases
3,Indoor fixed installation led display application cases
4,Outdoor fixed installation led display application cases
5,Outdoor mobile led display application cases
6,Flexibly curved led display application cases
Packaging & Shipping
Packaging:
1.The led display modules are packed in cartons.
2.The cabinets of fixed led screen packed in wooden case.
3.The cabinets of rental led screen packed in flight case.
The inner packing: Bubble wrap used to prevent product scratches and pressure damage.
Shipping:
We have three modes of transport:
1. Express:The most popular mode of transport,space and time of full freedom,flexible,adaptable.
2. Sea transportation:Large transportation capacity,high transport freedom.
3. Air transportation:Fast transport speed,smooth operation,less damage to goods.
Our Services
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Other services, such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
Warranty:
We guarantee all our displays, modules, parts for two full years.
During this time, we will replace or amend all our goods for free if there is something wrong with them. We provide lifetime maintenance and charge only for the raw materials.
We provide technology training for free, which contains the operation and maintenance training of the LED screens in the factory. Any associated CAD drawing on how to fix up the display and some other expert suggestion will be provided.
Company Information
Shenzhen JUCAIYUAN Photoelectric Co., Ltd devotes to developing, manufacturing and marketing Indoor & outdoor LED display products. Our company was established in 2012, having more than 5 years experience in supplying led display with good reputation in home and abroad.
We adhere to the principle of “efficient& high-integrity”, strictly follow by the requirements of ISO9001:2013 quality system, and insist on offering customers with excellent quality, reasonable price, sincere service and fast technical support. Our products are well exported to over than 70 countries, covering Asia, Middle East, America, Europe and Africa. Currently, we have obtained some patents in China, our products have various certificates, such as CE, FCC, CCC, ROHS ect.
If you are interested in any of our products or would like to discuss a project, please feel free to contact us, we are looking forward to forming successful business relationship with you. We hope to cooperate with more customers to reach win-win relationship.
FAQ
Q1.Can I have a sample order for led display product?
A:Yes, we welcome sample order to test and check quality. Both for LED module and whole screen.
Q2.What about the lead time?
A: Order less than 100 square meter led time take 15 working days.
Q3.Do you have any MOQ limit for led display order?
A:Low MOQ, 1 square meter or a module checking is available.
Q4.How do you ship the goods and how long does it take to arrive?
A:We mostly accept EXW term, but we can help you order and arrange shipping agent. It usually take 30 days on by sea and a few days for customer clearance. 6-7days by Air,4-5days by express.
Q5.How to proceed an order for led display?
A: First, let us know your requirements or applications.
Then, we quote according to your requirements or applications.
Third, customer confirms the design document and places deposit for formal order.
Last, we arrange the production.
Q6.Is it OK to print my LOGO on the led display product?
A:Yes, and please inform us formally before our production and confirm the design firstly based on our sample.
Q7.Do you offer guarantee for the products?
A:Yes, we offer 2year warranty to our product.
